Raptor 110
The Raptor 110 is built to bring maximum fun to ATV riders ages 10 and up. A new fuel-injected 112cc air-cooled SOHC 4-stroke engine is tuned to develop excellent low- to mid-range performance. A fully automatic CVT transmission with reverse, a gated shifter, and electric start all come standard.
Designed based on the top-selling Raptor 700R, this entry-level ATV brings Yamaha's Proven Off-Road sport ATV performance, legacy, and quality to new riders as they develop their skills and embrace their passion for motorsports.
Book a Test Ride
Schedule your Yamaha test ride today at Five Star Yamaha.
Available Colours
Team Yamaha Blue
Raptor 110
Get a Quote
Five Star Yamaha – where your quote is just a click away.
Features
Key Highlights
SPORTY 112CC ENGINE
The new fuel-injected 112cc four-stroke SOHC engine is tuned to develop excellent low- to mid-range performance, just where it's needed. The engine is air-cooled for simplicity, performance and long life, and uses ultra-reliable wet-sump lubrication.
SCALED DOWN NOT SCALED BACK
Compact A-arm front suspension is tuned for light, sporty steering and comfortable ride quality, with preload-adjustable shocks offering 127mm of wheel travel and adding to the Raptor 110's full-size ATV look. The rear swingarm also features a 5-way preload adjustable shock, offering 145mm of wheel travel.
MODERN RELIABLE ELECTRONICS
The new EFI system with an ECU delivers strong, reliable performance. A sealed, maintenance-free battery provides worry-free operation. Convenient handlebar-mounted reverse and neutral indicators, along with new engine warning and low-fuel warning lights keep the rider informed in all situations.
OPTIMISED TYRES
Duro low-profile tyres - AT18 x 7-8 front and AT18 x 9-8 rear - give the Raptor 110 aggressive looks and sporty handling.
Comfortable Chassis
An advanced frame design incorporates a large 6.7 litre fuel tank, plush seat and roomy integrated floorboards on an optimised wheelbase.
Request a Brochure
Discover the model — request your brochure today at Five Star Yamaha!
Specification
Technical Data
Engine Type
Air-cooled, 4-stroke, SOHC, 2-valve, single cylinder
Displacement
112 cc
Bore x Stroke
52.4 x 51.8 mm
Compression Ratio
9.2 : 1
Lubrication System
Wet sump
Fuel Management
Fuel Injection
Ignition
TCI
Starter System
Electric
Fuel Tank Capacity
6.8 L
Final Transmission
Chain
Transmission
V-belt automatic, F, N, R
Frame Type
Steel Tube
Suspension Front
Single A-arm, 127mm travel
Suspension Rear
Swingarm, 145mm travel
Brakes Front
Dual drum
Brakes Rear
Drum
Tyres Front
AT 18 x 7-8
Tyres Rear
AT 18 x 9-8
Length
1485 mm
Width
1020 mm
Height
991 mm
Seat Height
750 mm
Wheelbase
1030 mm
Ground Clearance
210 mm
Wet Weight
130.4 kg
